| Place of Origin: | China |
|---|---|
| Brand Name: | ESTY |
| Certification: | ISO/SGS |
| Model Number: | ESD |
| Minimum Order Quantity: | 100SQM |
| Price: | price discussion |
| Packaging Details: | 28pcs/box ,32-36box/pallets,13pallests/20GP |
| Delivery Time: | 7-10 work days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 1000000 Square Meter/Square Meters per Month |
| Product Name: | 590 * 590Mm Anti Static Pvc Flooring Pvc Flooring Conductive Floor Tile | Certificate: | ISO9001 |
|---|---|---|---|
| Wear Group: | P | Thickness: | 2-3mm |
| Size: | 600*600mm,590*590mm,610*610mm | Place Of Origin: | Jiangsu, China |
| High Light: | anti static flooring,anti static vinyl flooring |
||
Application
Electronics, microelectronics
Telecommunications environment
Raised Access Floor
Healthy Equipment
Clean Room
Computer Room
Electric Equipment
Product Specification
|
|
Technical Data |
Test Method |
Test Results |
|
1 |
Size |
EN426 |
600 x 600mm, 900 x 900mm |
|
2 |
Thickness |
EN426 |
2.0mm, 3.0mm |
|
3 |
Weight |
EN430 |
3.8kg / 5.7kg |
|
4 |
Electric Properties |
DIN51953 ASTM F-150 OR NFPA99 |
Antistatic Tile: 10^6~10^9 ohm |
|
5 |
Conductive Tile: 10^4~10^6 ohm |
||
|
6 |
Decay Time |
SJ/T10694-2006(±1000V±100V≤2s) |
<0.3S |
|
7 |
Charge Voltage |
SJ/T10694-2006(ⅠVⅠ<100V) |
70V |
|
8 |
Fire Resistance |
DIN4102 |
B1 |
|
9 |
Combustion Properties |
SJ/T11236-2001(<10S,reach FV-0) |
0.35IFV-0 |
|
10 |
Amount of Anti Wear |
SJ/T11236-2001(≤0.020g/cm 21000r) |
<0.014 |
|
11 |
Anti Wear Properties |
EN660pt2 |
ITEN-T<2.0mm3 |
|
12 |
Wheel Pressure |
EN425 |
No influence |
|
13 |
Residual Conavity |
EN433/DIN51955 |
0.03mm |
|
14 |
Dimension Stability |
|
≤0.10% |
|
15 |
Color Fastness |
ISO105BO2 |
>6 |
Packing & Shipping
|
thickness |
packing details |
|
2mm |
28pcs/box ,32-36box/pallets,13pallests/20GP,4500sqm/20GP |
|
3mm |
28pcs/box ,30-32box/pallets,13pallests/20GP,3200sqm/20GP |
